ART USB PHONOPLUS PS RIAA Preamplifier
Estimated delivery in Italy between 16 and 18 June
Paga in 3 rate da €32,66 senza interessi
Paga a rate con PayPal, se disponibile al checkout
Dilaziona il pagamento in comode rate mensili con la tua carta
Acquista ora e paga a rate. Calcola la tua rata con Findomestic
Sei un'azienda o un professionista con partita IVA? Richiedi il Noleggio operativo con Grenke
RIAA Preamplifier
The ART USB PHONOPLUS PS is a RIAA preamplifier with a low-noise phono pre-amp circuit and high-pass filters (to eliminate background noise), ensuring pristine audio acquisition. The gain control and Signal/Clip LED on the front panel allow for easy optimization of a wide range of analog input sources. The USB Monitor/headphone provides latency-free monitoring of the input source.
The ART USB PHONOPLUS PS also functions as an audio source player for any computer or laptop equipped with a USB port. The TOSLINK optical input and output, as well as the S/PDIF input, make the ART USB PHONOPLUS PS the perfect analog/digital to USB audio interface. The low-noise Phono Preamp circuit is highly accurate and fully compliant with RIAA standards. The jack line outputs are always connected to the preamplifier's input signal for source monitoring or to allow it to be used as a stand-alone phono preamplifier.
Housed in an all-black anodized aluminum chassis, the ART USB PHONOPLUS PS can be powered either by an external power supply or directly via USB. To ensure maximum versatility, the ART USB PHONOPLUS PS is fully compatible with USB 2.0 specifications. It is compatible with audio device drivers for Windows (98SE, ME, 2000, XP, Vista, 7) as well as Apple computers (OS9.1, OS-X) with native USB support.
The ART USB PHONOPLUS PS comes with SoundSaver Express software.
Specifications
- Frequency Response: 10 Hz - 50 kHz, +/- 0.5%
- THD: <0.01% typical @ 1 kHz
- Hum and Noise: > 90 dB below clipping
- Input Impedance: 47k Ohm / 100pf (phono), 270k Ohm (line)
- Maximum Input Level: 40 mV rms @ 1 kHz (phono), +19dBu (line)
- Maximum Gain: 45dB @ 1 kHz (phono), 6dB (line)
- Analog Input Connections: RCA (preamplifier / phono / line out)
- Analog Output Connection: RCA (preamplifier line out) // 1/8 inch (monitor/headphone out)
- Maximum Output Level +6dBu (1.4 V rms)
- Filter Type / Response: Switchable, High-Pass (low cut) -3dB @ 22 Hz
- A/D-D/A: 16 bit, 44.1 kHz or 48 kHz, USB selectable from computer // A/D Latency 0.4 ms @ 44.1 kHz
- Digital Audio Interface: TOSLINK Opto In to USB // TOSLINK Opto Out from USB // S/PDIF Coaxial Input (RCA) to USB
- Computer Interface: USB Class compliant plug-and-play interface for Mac and PC
- Chassis Type: All black anodized aluminum with integrated rubber sides
- Power Requirements: USB bus powered or 7-12V DC or 9-12V AC @ 150mA (external) // Both tip polarities will work with DC power
Couldn't load pickup availability
About Art
ART (Applied Research and Technology) is an American brand specializing in the production of accessible and reliable professional audio equipment. The ART range includes microphone preamps, signal processors, compressors, equalizers, splitters, direct boxes, phantom power supplies, and audio interfaces, all designed to deliver quality performance at a competitive price. ART products are used in recording studios, live performances, broadcast, and audio installations worldwide. Thanks to their ease of use and robust construction, ART is an ideal choice for musicians, sound engineers, and technicians. Discover the ART range on musicdelivery.net to integrate your audio setup with professional solutions offering unbeatable value for money.
