Blackmagic Design Mini Converter - Optical Fiber 12G
Estimated delivery in Italy between 13 and 15 October
Pay in 3 installments of €58,00 interest-free
Pay in 3 installments of €58,00 interest-free with PayPal
Split into 3 installments of €58,00 with your card via HeyLight
Are you a company or a professional with a VAT number? Request Operational Leasing with Grenke
FEATURES
The Mini Converter Optical Fiber 12G converts SDI to optical fiber and optical fiber to SDI simultaneously and in both directions, even with different video standards running in each direction.
Thanks to its multi-rate 12G-SDI connections, it is compatible with all SD, HD, and Ultra HD formats and equipment up to 2160p 60, including Level A and B devices. Any standard 3G, 6G, or 12G-SDI SFP optical fiber module can be installed to allow SDI transmission even over low-cost optical fiber cables, such as those commonly used for computer networks.
SPECIFICATIONS
- SDI video inputs: 1 x SD, HD and 12G-SDI video and 1 x optical fiber input
- SDI video outputs: automatically matches the SD, HD and 12G-SDI video input on the optical fiber
- Optical fiber video: inputs 1 x 10 bit SD/HD/12G- SDI switchable
- Optical fiber video outputs: automatically matches the SD, HD and 12G-SDI video input
- Optical fiber audio inputs: 16 channel embedded
- Optical fiber audio outputs: 16 channel embedded
- Multi rate support: auto detection of SD, HD or 12G-SDI
- Reclocking: yes
- SDI video standards: 525i 59.94 NTSC, 625i 50 PAL
- HD video standards: 720p 50, 720p 59.94, 720p 60, 1080p 23.98, 1080p 24, 1080p 25, 1080p 29.97, 1080p 30, 1080p 47.95, 1080p 48, 1080p 50, 1080p 59.94, 1080p 60, 1080PsF 25, 1080PsF 29.97, 1080PsF 30, 1080i 50, 1080i 59.94, 1080i 60
- 2K video standards: 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
- Ultra HD video standards: 2160p 23.98, 2160p 24, 2160p 25, 2160p 29.97, 2160p 30, 2160p 50, 2160p 59.94, 2160p 60
- 4K Video Standards: 4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
- SDI compliance: SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M, SMPTE, SMPTE ST-2081, ITU-R BT.656, ITU-R BT.601 and SMPTE 297M for optical fiber SDI
- SDI video rates: SDI video inputs are automatically detected between standard definition, high definition, level A or level B 3G‑SDI, 6G-SDI and 12G-SDI
- SDI video sampling: 4:2:2 and 4:4:4
- SDI audio sampling: television standard sample rate of 48 kHz and 24-bit
- SDI color precision: 4:2:2 and 4:4:4
- SDI color space: YUV and RGB
- SDI auto switching: automatically detects SD, HD or 12G-SDI
- ASI support: yes
- No user controls
- Mac 10.15 Catalina, Mac 11.1 Big Sur or later, Windows 10, 64-bit
- Power consumption: 2 W
- Operational voltage range: 6 to 36 VDC
- Operating temperature: 0 to 40 °C
- Storage temperature: -20 to 45 °C
- Relative humidity: 0 to 90% non-condensing
- Dimensions: 110 x 59 x 23 mm
- Weight: 210 g
Technical characteristics
Connections
Standards
Settings control
Operating systems
Power requirements
Environmental specifications
Physical specifications
