DAP-Audio GIG-143 TAB
Estimated delivery in Italy between 16 and 18 June
Paga in 3 rate da €225,66 senza interessi
Paga a rate con PayPal, se disponibile al checkout
Dilaziona il pagamento in comode rate mensili con la tua carta
Acquista ora e paga a rate. Calcola la tua rata con Findomestic
Sei un'azienda o un professionista con partita IVA? Richiedi il Noleggio operativo con Grenke
14-channel digital mixer, including dynamics and DSP
The GIG-143 TAB digital mixing console is the first 19" 3U rackmount digital mixing console in the GIG range produced by DAP-Audio. It is a mixing console that features all the functionalities of larger digital mixers available on the market. It has 8 XLR/TRS combo inputs and 3 stereo TRS inputs, all equipped with a gate, compressor, and full 4-band parametric equalizer on each input channel. The 2 analog outputs are equipped with a compressor as well as a 31-band graphic equalizer. Despite this compact digital mixer having a multitude of functions, DAP Audio has managed to design an interface that is understandable by all users, regardless of their level of experience. To this end, DAP-Audio has added dedicated direct access buttons for all important functions a sound engineer might need during their performance. This way, the user can directly access the desired function without getting lost in complex menu structures. Direct control is essential live, which is why all channels are equipped with an input fader and are always automatically assigned to the main parameter of the selected functionality. In this way, the console also offers an "analog" feel in the digital environment. The GIG-143 TAB features a bright OLED screen, 4 dedicated AUX outputs and a "control room" output, 1 integrated effects engine, 6 user-definable DCAs, and an internal 24-bit/48kHz sampling rate: all these elements make this product the most complete and interesting digital mixing console in its market segment. Features: • Bright OLED screen • Easy-to-use software interface • 8 direct access buttons for easy channel control • Digital Gate/Compressor/Full 4-band Parametric EQ on each input • 31-band Graphic EQ on each output • 14 analog inputs • 4 AUX sends (pre/post switchable per channel) • Separate control room output • 24-bit FX engine • Discrete, ultra-low noise preamps with +48V Phantom power • High-definition ADC (114dB dynamic range) • 6 user-definable DCAs • Full 24-bit/48KHz sampling rate • Separate headphone outputs with volume control
SPECIFICATIONS
- Mono Channels
- Mic Inputs: Balanced XLR
- Line Input: Balanced TRS
- Frequency Response: 20Hz ~ 20kHz, +/- 1.5dB
- Distortion (THD-N): <0.01% @ 0dB, 22Hz ~22kHz
- Maximum Input Level: +20dBu
- Signal-to-Noise Ratio: < -108dBr
- Phantom Power: +48V
- Stereo Channels
- Line Input: Balanced TRS
- Frequency Response: 20Hz ~ 20kHz, +/- 1.5dB
- Distortion (THD-N): <0.01% @ 0dB, 22Hz ~22kHz
- Maximum Input Level: +20dBu
- Signal-to-Noise Ratio: < -108dBr
- LowPass: 19.2kHz
- Frequency Range: 20Hz ~ 20kHz
- Gain: 0dBu +/- 18dB
- Q Factor: 0.4 ~ 128
- HighPass: 19.7Hz
- Threshold Range: -75dB ~ 0dB
- Attack Time 0.5ms ~ 200ms
- Release Time: 10ms ~ 1000ms
- Ratio: 1:1 ~ 1:10 up to gate
- Threshold Range
- Compressor: -30dB ~ +20dB
- Hold Time: 10ms ~ 150ms
- Release Time: 10ms ~ 1000ms
- Ratio: 1:1 ~ 1:10 up to limit
- Gain: 0 ~ +24dB
- Impedances
- Microphone Input: 6.8K Ohms
- Other Inputs: 27K Ohms
- Other Outputs: 120 Ohms
- Power Supply: AC 100~240V 50Hz/60Hz
- Power Consumption: 40W
- Measurements: 483 (19") x 134 (3U) x 321mm
- Weight: 7.2kg
Couldn't load pickup availability
About DAP-Audio
DAP-Audio is a brand of the Dutch group Highlite International, specializing in the production of professional audio equipment for events, installations, and live shows. The DAP-Audio range includes active and passive loudspeakers, power amplifiers, mixers, microphones, portable PA systems, and audio racks, all designed to offer reliable performance and excellent value for money. DAP-Audio products are chosen by sound engineers, DJs, bands, rental companies, and event organizers who need robust and versatile audio solutions. On musicdelivery.net, you can purchase the complete DAP-Audio line to best equip any event, from small venues to large stages.
