Satellite Line-Array
The DAP-AUDIO ODIN T-8A is a 2-way full-range Line-Array satellite. Audio quality is extremely important. That's why the DAP-AUDIO ODIN T-8A features two 8" neodymium midrange woofers and two 1" Celestion neodymium compression drivers. A custom-designed waveguide and DSP-optimized amplification guarantee excellent performance.
The housing also plays an important role. High-quality materials keep the unit safe during handling and transport, as well as when it's in the field. The enclosure is perfect, with an 18mm robust birch plywood housing and an easy-to-manage 3-point rigging system.
Specifications
- System: 2-way full range, active array element
- AMP Power: 800W continuous, Bi-AMP (Class D-650W LF, Class AB-150W HF)
- Peak: 3200W
- 2 x 1” Celestion Neodymium compression drivers, 1.75” voice coil, 80W RMS, 320W Peak
- 2 x 8” Celestion Neodymium MID woofers, water-resistant coating, 2” voice coil, 400W-RMS/1600W Peak
- Frequency Response: (+/-3dB) 80 Hz - 19 kHz
- Max SPL at 1 meter: 129dB
- Crossover Frequency: 1.6 KHz
- Dispersion (-6dB): 100° horizontal / 10° vertical
- Cooling: Passive cooling + forced internal cooling
- Audio Connector: XLR input and output
- Data Connector: RJ45 data input & daisy chain link connector
- External Controls: 9 fixed presets + 1 editable preset, switch with LED indicators for Clip/SIG/PROT
- DSP Processor: 32 bit, 24bit/48kHz AD/DA audio conversion
- Electronic Protections: Thermal/Convection-Fan/Overload/Digital limiter/Compressor
- Power Adapter: Neutrik PowerCON input and output connector
- Power Supply: 100 ~ 240VAC, 50Hz/60Hz
- Power Consumption: 1100W
- Housing Structure: 18mm birch plywood, durable black finish, 1.5T metal grille with foam, two handles per side, water-resistant coating
- Mounting: 3-point suspension, horizontal trapezoid 2 x 6.5°
Couldn't load pickup availability
Accessori consigliati
User Manual
Official technical documentation in PDF format.
About DAP-Audio
DAP-Audio is a brand of the Dutch group Highlite International, specializing in the production of professional audio equipment for events, installations, and live shows. The DAP-Audio range includes active and passive loudspeakers, power amplifiers, mixers, microphones, portable PA systems, and audio racks, all designed to offer reliable performance and excellent value for money. DAP-Audio products are chosen by sound engineers, DJs, bands, rental companies, and event organizers who need robust and versatile audio solutions. On musicdelivery.net, you can purchase the complete DAP-Audio line to best equip any event, from small venues to large stages.
