DAP Splash 10A 10" Active Full-Range Loudspeaker
Estimated delivery in Italy between 25 and 27 August
Pay in 3 installments of €68,33 interest-free
Pay in 3 installments of €68,33 interest-free with PayPal
Split into 3 installments of €68,33 with your card via HeyLight
Are you a company or a professional with a VAT number? Request Operational Leasing with Grenke
10" Active Full-Range Speaker
The DAP Splash 10A is a 10-inch active full-range on-the-road speaker with a maximum SPL of 116 dB at 1 metre. This speaker, with its built-in 240-watt amplifier, is perfectly suited for use as a stage monitor or as a PA speaker for small venues. It has a versatile design and delivers a crisp sound. The Splash 10A is compact and has a narrow dispersion angle to minimise potential feedback and maximise its output.The Splash series is designed to offer durability and exceptional performance. It has a robust ABS housing and features handles, a universal stand mount adapter, and rubber feet for quick and secure installation.
SPECIFICATIONS
- Low Driver Power: 90 W
- High Driver Power: 30 W
- Amplifier RMS Output Power: 120 W
- Amplifier Peak Power: 240 W
- Main Outputs: 1
- Main Output Connectors: 3-pin XLR
- Mono Inputs: 1
- Mono Input Connector: 3-pin XLR
- THD Level: < 0.5 %
- Signal-to-noise Ratio: > 80 dB
- Amplifier Class: Class D
- Damping Factor: 200 :1
- Speaker System: 2-way
- Speaker Sensitivity (1W/1m): 95 dB
- Max SPL at 1m: 116 dB
- Frequency Response (-6dB) Minimum: 65 Hz
- Frequency Response (-6dB) Maximum: 20000 Hz
- Crossover Frequency (High): 2800 Hz
- Woofer Diameter: 10"
- Woofer Voice Coil: 1.5"
- Woofer Magnet Type: Ferrite
- Driver Diameter: 1"
- Driver Voice Coil: 1"
- Driver Magnet Type: Ferrite
- Horizontal Dispersion Angle: 90°
- Vertical Dispersion Angle: 45°
- Bluetooth: No
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 75 W
- Fuse: 0.8 A
- Power Input Connector: IEC
- Amplifier Cooling: Convection
- Height (mm): 460 mm
- Width (mm): 285 mm
- Depth (mm): 265 mm
- Material: ABS
- Colour: Black
- Weight: 6.92 kg
- IP Rating: IP20 (Indoor use only)
- Stand Adapter: 35 mm
- Electronic Protections: Clip limiter (fixed) / DC voltage / Softstart / Thermal
- LED Indicators: Clip / Power / Signal
- Rotatable Horn: No
- Monitor Use: Yes
- Speaker Grille: Steel
- Speaker Handles: Top
- Included Cables: IEC cable
Couldn't load pickup availability
User Manual
Official technical documentation in PDF format.
