EUROLITE LED KLS Scan Next FX Compact Light Set
Regular price
Sale price
€723,90
Regular price
€762,00
-5%
Tax included.
Shipping calculated at checkout.
Caricamento stato...
Estimated delivery in Italy between 16 and 18 June
Paga in 3 rate da €254,00 senza interessi
Paga a rate con PayPal, se disponibile al checkout
Dilaziona il pagamento in comode rate mensili con la tua carta
Acquista ora e paga a rate. Calcola la tua rata con Findomestic
Sei un'azienda o un professionista con partita IVA? Richiedi il Noleggio operativo con Grenke
Compact bar with derby, spots, scanners, UV effect, QuickDMX and bag
Everything in one compact lighting set: basic light, effects and scanners. The KLS Scan Next FX LED is equipped with 4 spots for colourful basic lighting, UV LEDs for the popular ultraviolet light effect and a derby effect for party atmosphere. But the special feature of this bar is the equipment with two integrated scanners including a gobo wheel and a colour wheel. The two scanners are each equipped with a very effective 15-watt LED.
CONTROL VIA STANDALONE, REMOTE CONTROL AND FOOT SWITCH
The control options of the KLS offer something for every user: even without an external controller, 20 different programs can be set that run automatically or are music-controlled. These programs offer well thought-out and carefully selected shows in terms of colour. The various programs can be called up and colourful atmospheres created via the supplied infrared remote control. Control via an optional foot switch is also possible.
DIFFERENT DMX MODES
There are ten different DMX modes: In the smallest mode with three channels, automatic and music-controlled programs can be called up and switched. The largest mode with 39 channels allows full control of each spot, the derby and the scanners. In some modes, the two scanners are controlled together. In the menu it is then possible to set that one or both movement axes should be inverted, i.e. mirrored. This simplifies control and results in a consistent image.
WIRELESS DMX
The KLS has a USB socket for QuickDMX. An optional DMX wireless adapter can be plugged into this to realise wireless DMX transmission. This works not only from a console to KLS bars, but also with several KLS units for master-slave operation.
SPECIFICATIONS
- DMX light effect bar with 1 rotating LED derby, 4 LED spots, 2 scanners and UV LEDs
- Ultralight, ideal for mobile use
- Crossbar with integrated DMX control unit and TV spigot for tripod installation
- Swivelling mounting brackets
- Comes pre-assembled with practical transport bag
- Convenient control via included IR remote control or optional wireless foot switch
- Several different DMX modes for various consoles and requirements
- LED derby and LED spots individually adjustable and controllable
- Spots with 15° beam angle
- Mirror movement can be inverted separately for both scanners (e.g. for common counter-rotating control)
- Brand-new software design with intelligent programs
- 20 built-in show programs for music and auto mode that include all 4 effect units
- Control panel with OLED display for easy configuration
- Supports QuickDMX - the wireless DMX system from Eurolite
- Integrated USB port with phantom power for QuickDMX, CRMX and WDMX receivers (optional)
- When using a smoke machine, this effect becomes particularly attractive
- Mains input and output for power linking up to 8 units
- Can be operated in 3; 7; 13; 14; 15; 18; 19; 30; 32; 39 CH mode
- The device is cooled by cooling fan
- Control via DMX; IR remote control (provided); Sound to light via Microphone; Stand-alone; Master/slave function; Wireless foot switch (optional); QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
- For areas of application such as: Wedding/gala; rental; small rental
- Spotlight
- LED: Spot each 3 x 7 W 4in1 QCL RGB/WW high-power (homogenous color mix)
- Light effect
- LED: Multi beam effect each 1 x 3 WR/G/B
- Moving light
- LED: Scanner each 1 x 15 W cool white (CW)
- Bar
- LED: 4 x 1 W ultra violet (UV) high-power
- Power supply: 100-240 V AC, 50/60 Hz
- Power consumption: 115 W
- IP classification: IP20
- Protection class: Class I
- Power connection: Mains input P-Con (blue), mounting version power supply cord with safety plug (provided)
- Power output: P-Con (grey), mounting version
- Fuse: 5 x 20 mm, T 2 A replaceable fuse
- Lamp type: LED lamp
- Equipment: Color wheel; gobo wheel with static gobos
- DMX channels: 3; 7; 13; 14; 15; 18; 19; 30; 32; 39
- DMX input: 1 x 3-pin XLR (M) mounting version
- DMX output: 1 x 3-pin XLR (F) mounting version
- Cooling: Cooling fan
- Control: DMX; IR remote control (provided); Sound to light via Microphone; Stand-alone; Master/slave function; Wireless foot switch (optional); QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
- Beam angle: 15°
- Beam angle (1/2 peak): Spot 15°
- Beam angle (1/10 peak): Spot 28°
- Illuminance in Lux (lx): Red (R) 1 m: 1022 lx, 3 m: 125 lx, 6 m: 33 lx
- Green (G) 1 m: 2448 lx, 3 m: 285 lx, 6 m: 75 lx
- Blue (B) 1 m: 395 lx, 3 m: 47 lx, 6 m: 13 lx
- Warm white (WW) 1 m: 1892 lx, 3 m: 219 lx, 6 m: 58 lx
- All 1 m: 4853 lx, 3 m: 676 lx, 6 m: 175 lx
- Housing color: Black
- Fixing system: TV spigot Ø 28mm
- Display type: OLED display
DIMENSIONS
- Width: 1.1 m
- Depth: 15.5 cm
- Height: 43 cm
- Weight: 12.80 kg
