IK MULTIMEDIA ILOUD MTM-WHITE Studio Monitor

Studio Monitors

IK MULTIMEDIA ILOUD MTM-WHITE is a studio monitor characterized by an absolutely neutral frequency response and a perfect sound image even at short distances.
What a studio monitor must guarantee is a neutral, accurate, and balanced representation of the program, so that the mix can translate correctly on any playback system. IK MULTIMEDIA ILOUD MTM-WHITE uses the most advanced DSP techniques to ensure total control over speaker performance, guaranteeing results simply unattainable with traditional analog designs.
The high frequencies are neutral and defined, the mids are precise and transparent, and the low frequencies are extended and balanced. Of course, it's “loud”, with 100 RMS per speaker and 103dB SPL maximum sound pressure.
IK MULTIMEDIA ILOUD MTM-WHITE offers an extended response down to 40Hz, a fundamental range for providing a complete picture of modern productions.
With IK MULTIMEDIA ILOUD MTM-WHITE, it introduces the new and exclusive patent-pending Physical Response Linearization (PRL™) system. This technology combines a precise physical model of the electroacoustic system and measurements taken on real units to achieve optimal low-end performance linearization. The result is a surprisingly solid, balanced, and defined low-end, with precision capable of surpassing systems significantly larger than MTM.
The advanced DSP processing of IK MULTIMEDIA ILOUD MTM offers an accurate phase response across the useful frequency spectrum.
IK MULTIMEDIA ILOUD MTM-WHITE uses a symmetrical midrange-tweeter-midrange design with a pair of high-performance 3.5-inch mid-woofers and a 1-inch high-resolution tweeter with a loading chamber, which guarantees an ultra-precise and defined sound that traditional two-speaker systems simply cannot achieve, especially when listened to at close distances. Furthermore, this system minimizes hearing fatigue caused by traditional 2- or 3-way designs, where different frequencies reach the ear at different times.
The design of IK MULTIMEDIA ILOUD MTM-WHITE also offers exceptional sound dispersion, optimizing transparency and neutrality and minimizing the impact of room acoustics for even more accurate monitoring.
In addition to all this, this innovative design minimizes the size of the monitors, which are 30 to 50% smaller than monitors with similar features, so you can have them with you even in smaller spaces.
IK MULTIMEDIA ILOUD MTM-WHITE offers an integrated acoustic auto-calibration system, so that the frequency response automatically adapts to the positioning. Simply place the monitors where the studio allows, position the microphone, press a button, and you will instantly have a calibration based on the listening environment. Furthermore, it is possible to adapt the low-frequency extension and fine-tune the level of low or high frequencies according to your preferences.
IK MULTIMEDIA ILOUD MTM-WHITE uses uncompromising A/D and D/A conversion, very high-resolution algorithms to manage linear phase digital crossover filters, alignment, equalization, dynamic range, and auto-calibration. Fully controlled by DSP and perfectly time-aligned between the two ways, iLoud MTM has a controlled off-axis response to minimize the effect of reverberation introduced by the listening environment.

Specifications

• Type: 2-way / 3-speaker bi-amplified, digitally controlled studio monitor
• LF Driver: 2x custom 3.5" polypropylene woofers
• HF Driver: 1" high-definition, low-distortion back chamber silk dome tweeter
• Acoustic Design: DSP tuned bass reflex
• Number of Amplifiers per Speaker: 2
• Amplifier Type: High-efficiency Class D
• Total Power: 100 W RMS
• LF Power: 70 W RMS
• HF Power: 30 W RMS
• Crossover Type: Linear phase variable order
• Crossover Frequency: 3.1 kHz
• Frequency Response: 50 Hz to 24 kHz +/- 2 dB (40 Hz -6 dB uncal, -3 dB cal)
• Phase Response: System remains coherent within +/- 15° from 200Hz to 20kHz
• Sensitivity at +4dBu: 0dBu signal generates 100 dB SPL at 1 m
• Sensitivity at -10dBV: -11dBu signal generates 100 dB SPL at 1 m
• Maximum SPL at 1 m, one speaker playing, on-axis: 103 dB from 200 Hz sine wave, 95 dB at 100 Hz sine wave, 93 dB pink noise
• Positioning Settings: Manual switches for LF extension, LF trim, HF trim, Desk position
• LF Extension: Switch sets -3 dB of frequency response at 40, 50, or 60 Hz
• LF Switch: Low shelf, +2dB or -3dB from 100Hz down
• HF Switch: Hi shelf, +2dB or -2dB from 8kHz up
• Desk Switch: -4dB at 160Hz and +1dB at 1.8kHz
• Calibration: Fully automatic integrated digital calibration, microphone included
• Measurement Microphone: Mems-based omnidirectional precision measurement microphone
• Full DSP Control
• Connectors: 1x combo XLR-1/4" balanced TRS input; 1/8" TS ARC microphone input, 1x USB type B (for service only), AC POWER socket
• Power Requirements: 90 to 240 V AC, auto-range, 50 or 60Hz, 120W maximum consumption
• Color: White

Package Includes

• 1 iLoud MTM monitor
• Power cable
• ARC microphone
• ARC microphone clamp
• ARC microphone cable
• Tilting stand
• Horizontal support feet
• Locking key
