INFINITY Furion FX402 Bar 10x 60W RGBW LED FX Bar with Strobe Pixels - IP65

10x 60 W RGBW LED FX Bar with pixel strobes - IP65

The Infinity Furion FX402 bar is an IP65 rated LED strip with 10 powerful 60-watt RGBW LEDs in 10 tiltable heads with zoom and 60 warm and cool white strobe pixel LEDs. It creates unique lighting effects, sparking creative ideas for live events, TV shows, clubs, and theater, and more.
The RGBW LEDs can be individually controlled, as can the tilt and zoom of each head, offering flexible and smooth control over lighting effects and coverage. Each tiltable head features 6 individually controllable CW strobe pixels and 6 WW strobe pixels, alternately placed, which add intricate accents to an already impressive light output. The heads can be tilted over 200 degrees, while the beam angle can be adjusted between 2.7° and 31.4° for each head individually, thanks to the high-precision motorized zoom.
With Art-Net and sACN, it's easy to integrate the Furion FX402 Bar into any professional infrastructure. In DMX mode, the fixture can be controlled from 29 channels up to an intelligently configured advanced mode with 255 channels, meaning two fixtures can be controlled from a single DMX universe in the most advanced DMX mode. The Furion FX402 Bar can be controlled via DMX/RDM, manually, and has an automatic mode, which offers comprehensive options. The refresh rate (PWM) can be adjusted between 600 and 15,000 Hz to suit studio and TV applications, while the high-resolution dimming function provides precise control over the amount of light emitted.
The FX402's magnesium and forged aluminum body is robust and lightweight, ensuring durability and minimal maintenance. The IP65 rating protects it from dust and water, making it suitable for both indoor and outdoor use. Aligning multiple fixtures has been made easier thanks to the extendable pins on one side and corresponding holes on the other. Seamless edge-to-edge mounting keeps the tiltable heads of different fixtures at the same distance, creating homogeneous runway effects.
With the Furion FX402 Bar, lighting designers have access to an exquisite professional strip light effect that combines power and creativity with fluid movements in a durable design.

SPECIFICATIONS

• Light Source Type: LED
• Light Source Quantity: 10
• Light Source Power: 60 W
• LED Colour: RGBW
• Refresh Rate: 600 Hz
• Refresh Rate (max): 15 kHz
• Lumen Total: 8951 lm
• CRI: 83.7
• CCT: 7200 K
• Beam Angle Circular (min): 2.7°
• Beam Angle Circular (max): 26.7°
• Cut-off Angle Minimum (circular): 3.8°
• Cut-off Angle Maximum (circular): 31.4°
• Field Angle Minimum (circular): 3.4°
• Field Angle Maximum (circular): 30.3°
• Zoom Type: Motorised
• Zoom Ratio: 1:10
• Control Mode: Auto / DMX / Manual
• DMX Channels: 29 / 56 / 144 / 255
• Protocols: Art-Net / DMX / RDM / sACN
• Display: TFT
• Dimmer Curve: Linear / Square / I-Square / S-Curve
• Control Zones (sections): 10
• Dimmer Resolution: 16 bit
• Zoom Resolution: 8 bit
• Dimmer: 0-100 %
• Strobe: 0-20 Hz
• Pan: 0°
• Tilt: 200°
• Pan/Tilt Resolution: 16 bit
• Power Supply: 100-240 V AC 50/60 Hz
• Power Consumption: 800 W
• Fuse: 15 A
• Power Input Connection: Power Pro True
• Power Output Connector: Power Pro True
• DMX Connection: XLR 5P In/Out
• DMX Input Connection: XLR 5P
• DMX Output Connection: XLR 5P
• Data Connection: etherCON In/Out
• Data Input Connection: RJ45
• Data Output Connection: RJ45
• Length (mm): 1000 mm
• Width (mm): 209 mm
• Height (mm): 322 mm
• Weight: 31 kg
• IP Rating: IP65
• Housing: Die-cast Magnesium
• Colour: Black
• Cooling: Convection
• Maximum Ambient Temperature: 45 °C
• Minimum Operating Temperature: -10 °C
• Cables Included: Power Pro True Cable
• Fixings Included: Quick-Lock Bracket
