3-channel Class-D 2.1 amplifier
The OMNITRONIC A-3603 is a 3-channel Class-D 2.1 amplifier for setups with two top speakers and one subwoofer.
The OMNITRONIC A-3603 provides enough power to drive a large speaker system with up to 3600 watts, 4 ohms (2000 W sub and 2 x 800 W top). Powerful enough for use in clubs, lounge bars, restaurants, dance schools, fitness studios, and similar venues.
Thanks to the crossover frequency control, you can adjust the frequencies between the tops and the subwoofer. It also features a bypass function, allowing you to connect a DSP speaker management system beforehand. You can also switch from 2-channel stereo input to 3 separate channels.
Specifications
- Power supply: 230 V AC, 50 Hz
- Output power (RMS): 1 x 2000 W or 2 x 800 W @ 4 ohms / 1 x 1000 W or 2 x 400 W @ 8 ohms
- Signal-to-noise ratio: > 100 dB
- Total harmonic distortion: < 0.003%
- Damping factor: > 500
- Voltage gain: 41.2 dB
- Slew rate: > 10 V / μsec
- Input impedance: 20 kohms (balanced), 10 kohms (unbalanced)
- Input connectors: 3 x XLR
- Output connectors: 3 x Speaker, 3 x XLR pass-through output
- Circuitry: Class D
- Controls: power switch, input attenuators, 2/3 channel mode switch, X-over frequency
- LED indicators: protection, clip, 0 dB, -10 dB, -20 dB (per channel)
- Construction: steel chassis, aluminum front panel
- Rack installation with 2 U
- Power consumption: 685 W 1/8 power
- Frequency range: 20 - 20000 Hz
- Power / channel (8 Ohm): 800 W
- Power / channel (4 Ohm): 2000 W
Dimensions
- Height: 89 cm
- Depth: 410 mm
- Width: 483 mm
- Weight: 9.10 kg
