RELACART R-14D Antenna Distribution System
Estimated delivery in Italy between 4 and 6 August
Pay in 3 installments of €150,38 interest-free
Pay in 3 installments of €150,38 interest-free with PayPal
Split into 3 installments of €150,38 with your card via HeyLight
Are you a company or a professional with a VAT number? Request Operational Leasing with Grenke
Antenna splitter (470 - 900 MHz)
- Active antenna splitter for operating up to four true diversity UHF receivers on one pair of multi-antennas
- Improves interference immunity and increases range
- Replaces the respective antennas and power supplies of the individual receivers
- Up to five R-14D antenna splitters can be cascaded for the use of 16 microphones in total
- Low-voltage outputs for powering four UHF receivers, including matching DC connection cables
- All antenna connections via BNC jacks, including 10 x BNC cable
- Use in the entire UHF frequency band 470 - 900 MHz
- (19") 48.3 cm rack installation
Scope of delivery
- 1 x device
- 1 x power cord
- 10 x BNC cable
- 4 x adapter cable
- 1 x user manual
- 1 x declaration of conformity
| Type: | Antennas and splitters |
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | Max. 60 W |
| Power connection: | Mains input IEC connector (M) mounting version power supply cord with safety plug (provided) |
| Impedance: | 50 Ohm |
| Gain: | Output: 0 dB |
| Frequency band: | UHF 470 - 900 MHz |
| Output voltage: | 4 x 12 V DC |
| Status LED: | Power |
| Connections: | Input: antenna via 2 x BNC (F) 8 V Output: antenna via 8 x BNC (F) |
| Switch: | On/off switch |
| Material: | Metal |
| Color: | Black |
| Housing design: | (19") 48.3 cm rack installation |
| Dimensions: | Width: 48.3 cm Depth: 24.2 cm Height: 4.45 cm |
| Weight: | 3.00 kg |
