Rondson AM 20N Preamplifier / amplifiers 20 W, 4 Inputs, 8 ohm, 25 / 70 / 100 V, 220 - 240 V AC / 12 V DC
Pay in 3 installments of €83,60 interest-free
Pay in 3 installments of €83,60 interest-free with PayPal
Split into 3 installments of €83,60 with your card via HeyLight
Are you a company or a professional with a VAT number? Request Operational Leasing with Grenke
CARATTERISTICHE
Amplificatore integrato / mixer con uscita per linea a 100 V, potenza 20 W. Oltre che le uscite altoparlanti a 25, 70 e 100 V, è presente quella a 8 ohm a bassa impedenza. Funzionamento con rete a 230 VAC o 12 VDC per AM 20N, AM 40N e 24 VDC per AM 60N.
Caratteristiche principali
- 1 ingresso microfono DIN/jack/XLR bilanciato MIC 1 (prioritario) tramite Talk-over o telecomando
- 1 ingresso microfonico bilanciato (jack/XLR), MIC 2. Questi 2 ingressi possono essere commutati su Phantom power (intervento all'interno del dispositivo), un segnale acustico (2 toni "ding dong") può essere attivato dal microfono MIC 1 collegato alla presa DIN a 5 poli (call station Rondson PA 100D) oppure sulla presa jack stereo sul pannello frontale (console Pa 100J)
- 1 ingresso telefonico, messaggio di emergenza, super priorità
- 2 ingressi AUX RCA (sintonizzatore, CD, ecc.)
- 1 uscita di linea per il collegamento ad un finale esterno
SPECIFICHE
Technical characteristics
| Type | amplifier / preamplifier |
| Power supply | 115 - 230 VAC 50/60 Hz - switchable ±10% 12 VDC (max. deviation 10%) |
| Output power | 20 WRMS 30 W max. |
| Speaker outputs | 8 ohm - 25 / 70 / 100 V |
| Line output | 1 V, 600 ohm |
| Inputs | MIC 1 / 2: 1 mV, 250 ohm symmetrical power supply configurable Phantom power supply AUX: 200 mV, 47 kohm asymmetrical TEL: 0.1 to 1 V, 600 ohm, symmetrical, adjustable |
| Frequency response | MIC 1 / 2: 60 Hz - 15 kHz ±3 dB AUX: 60 Hz - 15 kHz ±3 dB TEL: 100 Hz - 15 kHz ±3 dB |
| THD | Less than 1% at 1 kHz at RMS power |
| S/N ratio | all CCN volume settings: 75 dB below nominal power MIC 1 / 2: 60 dB below RMS power AUX: 70 dB below RMS power TEL: 70 dB below RMS power |
| Tone settings | bass: ±10 dB at 100 Hz - treble: ±10 dB at 10 kHz |
| Settings | MIC 1 / 2: volume control AUX: volume control - Tone: bass and treble TEL: entry level CHIME: inter ON/OFF 115 - 230 V: voltage switch |
| Display | power ON indicator light |
| Consumption | mains: 60 W, battery: 3 A |
| Chime | 2 tone ding dong preceding 1 microphone call |
| Priority | by detection / MIC 1 connected to DIN or jack |
| Priority levels | TEL/EMER MIC 1 MIC 2 AUX 3 2 1 1 |
| Option 19" rack mounting 2 U | mounting brackets EQ 2040 |
| Dimensions (W x D x H) | 27.2 x 30 x 8.8 cm |
| Weight | 4.2 kg |
