Rondson AM 30A Preamplifier / amplifiers, 30 W, 6 Inputs, 8 ohm, 25 / 70 / 100 V, 220 - 240 V AC / 24 V DC
Estimated delivery in Italy between 20 and 22 July
Pay in 3 installments of €123,77 interest-free
Pay in 3 installments of €123,77 interest-free with PayPal
Split into 3 installments of €123,77 with your card via HeyLight
Are you a company or a professional with a VAT number? Request Operational Leasing with Grenke
CARATTERISTICHE
Amplificatore integrato / mixer con uscita per linea a 100 V, potenza 30 W. Oltre che le uscite diffusori a 25, 70 e 100 V, è presente quella a 8 ohm a bassa impedenza. Funzionamento con rete a 230 VAC o 24 VDC.
Caratteristiche principali
- 1 x ingresso microfono DIN / jack / XLR bilanciato MIC 1 (prioritario) tramite Talk-Over o telecomando
- 2 x ingressi microfonici bilanciati (jack / XLR), MIC 2 e MIC 3. Questi 3 ingressi sono commutabili su Phantom power (intervento interno), MIC 3 commutabile in linea, un segnale acustico (2 toni "ding dong") può essere attivato dal microfono MIC 1 inserito nella presa DIN 5 poli (postazione microfonica PA 100D ) o sulla presa jack stereo sul pannello frontale (console PA 100J)
- 1 x ingresso telefonico, messaggio di emergenza, super priorità
- 2 x ingressi AUX RCA (sintonizzatore, CD, ecc.)
- 1 x ingresso e uscita per equalizzatore o amplificatore
- 1 x uscita di registrazione
- Uscite diffusori su morsettiera BI 8 ohm, HI 25, 70 o 100 V
- Ventola di raffreddamento
SPECIFICHE
Technical characteristics
| Type | amplifier / preamplifier |
| Power supply | 115 - 230 VAC 50/60 Hz - switchable ±10% 24 VDC (max. deviation 10%) |
| Output power | 30 WRMS 45 W max. |
| Loudspeaker outputs | 8 ohm - 25 / 70 / 100 V |
| Line output | 1 V, 600 ohm |
| Inputs | MIC 1 to 3: 1 mV, 250 ohm symmetrical configurable Phantom power supply AUX 1: 200 mV, 47 kohm asymmetrical AUX 2: 500 mV, 47 kohm asymmetrical TEL: 0.1 to 1 V, 600 ohm, symmetrical, adjustable Power IN: 1 V, 47 kohm, asymmetrical |
| Frequency response | MIC 1 - 3: 60 Hz - 15 kHz ±3 dB AUX 1 - 2: 60 Hz - 15 kHz ±3 dB TEL: 100 Hz - 15 kHz ±3 dB |
| THD | less than 1% at 1 kHz at RMS power |
| S/N ratio | all CCN volume settings: 75 dB below nominal power MIC 1 to 3: 60 dB below RMS power AUX 1 - 2: 70 dB below RMS power TEL: 70 dB below RMS power |
| Tone settings | bass: ±10 dB at 100 Hz - treble: ±10 dB at 10 kHz |
| Settings | MIC 1 to 3: volume control AUX 1 - 2: volume control MASTER volume control tone: bass and treble TEL: input level CHIME: inter ON/OFF 115 - 230 V: voltage switch |
| Consumption | mains: 90 W, battery: 2 A |
| Chime | 2 tone ding dong preceding 1 microphone call |
| Priority | by detection / MIC 1 connected to DIN or jack |
| Priority levels | TEL/EMER MIC 1 MIC 2 AUX/CD 3 2 1 1 |
| Option 19" rack mounting 2 U | mounting brackets EQ 2000 |
| Dimensions (W x D x H) | 43 x 26 x 8.8 cm |
| Weight | 6.5 kg |
