SGM STAGE 3

FEATURES

PALCO 3 is a compact and powerful Wash projector, designed for professional applications in the rental sector, temporary events, and dynamic productions.

Equipped with 18 x 40 W RGBL LEDs with Color Boost technology, it offers a calibrated output of approximately 16,000 lumens and a high color rendering index with a CRI of over 85 at 5600 K. The choice of RGBL (L = Lime) LEDs allows for very high quality and color precision. The device is divided into three individually controllable segments, ensuring creative flexibility and precision in light control.

One of the main strengths of PALCO is the absolute color consistency across all projectors, regardless of the time of purchase or the product version, whether it is a compact, medium, or high-end model. This aspect is crucial for industry professionals, as it allows for a homogeneous visual output even in mixed installations or subsequent upgrades. To achieve this level of precision, SGM adopts a sophisticated individual calibration process: every single LED inside the fixture is turned on and measured individually during production. This meticulous approach ensures that every unit meets the same color standards, offering predictable, stable, and perfectly aligned colors across the entire product line.

The foldable structure allows for a volume reduction of up to 50%, facilitating transport and storage, while the low weight of only 6 kg simplifies handling and rigging, as more units can be mounted.

PALCO 3 is designed to withstand harsh environmental conditions thanks to its robust recycled aluminum construction and IP65 protection against dust and moisture. It is compatible with major control protocols such as DMX, RDM, Art-Net, sACN, and features integrated wireless DMX connectivity, as well as NFC support via a dedicated App (iOS and Android) for quick configuration even without power, even when hundreds of units are being set up.

The 100 – 240 V_AC universal power supply and versatile mounting options make it an ideal solution for temporary and touring installations. Each unit includes rubber flight case inserts (foam shell) and rotating omega brackets, optimizing logistics and technical preparation.

PALCO 3 represents a perfect synthesis of light efficiency, operational practicality, and sustainability, offering high performance in a compact and intelligent format.

User Benefits

• Compact dimensions relative to brightness
• Intense light output
• High performance on white and primary colors, superior to any other direct competitor
• Predictable light and color quality
• Fits all control systems
• Useful for productions where cabling is problematic
• Allows for quick configuration and addressing, even in the flight case
• Universal mains power supply
• Total mounting flexibility
• Savings in setup costs
• Three-year warranty

Fields of application

• Most temporary installations, including outdoor
• Live events and theatrical shows
• Concerts and festivals
• Temporary productions
• Complex logistics situations
• Rental companies

SPECIFICATIONS

Technical characteristics

• 18 x 40 W RGBL LED with Color Boost Technology
• LED expected lifetime: 50,000 hours
• Peak calibrated output: 15,558 lumens
• Color rendering index (CRI): 85+ @ 5600 K
• Native beam angle: 11°
• 3 individually controllable segments
• Max. power consumption: 450 W
• Standby power consumption: 10 W
• IP65-rated for outdoor use
• Control protocols: DMX512, RDM, Art-Net, sACN
• Wireless control: LumenRadio CRMX built-in
• NFC configuration via proprietary iOS / Android App
• Input voltage: 100 – 240 V_AC 50/60 Hz
• Cooling: combined forced air and convection system
• Housing: cast in recycled aluminum
• Lens material: PMMA
• Mounting: multiple rigging options including vertical hanging
• Included accessories: rubber foam flight case insert and two ¼-turn omega brackets
• Max. humidity: 98%
• Temperature range, operating / start-up: -20 to 50 °C
• Dimensions (unfolded):  35.6 x 26.8 x 18.3 cm
• Dimensions (folded): 35.6 x 16.5 x 18.3 cm
• Weight: 7.5 kg
