Zzone ZZONEMTX16 16x16 Audio Matrix with DSP
Estimated delivery in Italy between 11 and 15 September
Pay in 3 installments of €613,00 interest-free
Pay in 3 installments of €613,00 interest-free with PayPal
Split into 3 installments of €613,00 with your card via HeyLight
Simulate your installment financing with Findomestic
Are you a company or a professional with a VAT number? Request Operational Leasing with Grenke
ZZONEMTX is a line of DSP audio matrices based on the SHARC ADP-21489 processor, designed for AV integration and controllable via ZZONEMTX DSP 3.0 software.
It supports the Dante protocol and communication with third-party systems via UDP, RS232, and RS485 protocols, enabling real-time audio routing and processing management.
The DSP operates at 40-bit floating point and integrates selectable and configurable algorithms such as Automixer, AEC, ANS, and AGC, as well as EQ, Gate, Compressors, and feedback suppressors, ensuring high headroom on audio signals. The line includes a 2x2 USB audio interface that can be used as a dedicated sound card.
The matrices are controlled via ZZONEMTX DSP 3.0, which allows system configuration and user interface customization for ZZONEMTX10T, PCs, and Android or iOS smartphones and tablets.
Download the application for iPad iOS: DSPPro_v2_2.2.29
Download the application for Android tablets: DSPPro_2.3.22.apk
| Feature | Specifications |
|---|---|
| DSP | SHARC ADSP-21489 - 450MPS 2.7GFLOPs |
| Analog Inputs | 16 Mic/Line on terminal blocks |
| Analog Outputs | 16 line level on terminal block |
| Phantom Power | +48V (Max 10mA selectable per input) |
| Interfaces | LAN 10/100 |
| Connections | RJ45, USB Type A, RS232, RS485, Terminal Block |
| Audio Input Gain | 0-60dB in 3 dB steps |
| Frequency Response | 20Hz - 20KHz (+/-0.3dB) |
| Sample Rate | 48KHz |
| Bit Depth | 24 |
| Max Level | +18dBu |
| EIN | <-125dB, 20Hz - 20KHz A-weighted |
| Background Noise | -95dB A-weighted |
| THD | 0.003% @ 4 dBu |
| A/D Dynamic Range | 110dB |
| D/A Dynamic Range | 112dB |
| Channel Isolation | 108dB |
| Balanced Input Impedance | 5.4 KOhm |
| Balanced Output Impedance | 600 Ohm |
| System Latency | <5ms |
| Power Supply | 110-240V 50Hz-60Hz |
| Max Power Consumption | 40W |
| Dimensions | 482 x 264 x 44mm |
| Net Weight | 2.2Kg |
| Gross Weight | 3.2Kg |
